ENGINE |
|
|
Emission Standard |
Euro 5,EPA4 |
|
Make /Model |
KUBOTA /D722 |
|
Power /Rotation speed |
10.2kw(14HP)@2500rpm |
|
Number of cylinder |
3 |
|
TRACK DRIVING SYSTEM |
|
|
Max. travel speed |
2.1km/h |
|
Maximum Travel speed(High/low) |
3.5/2.1km/h(optional) |
|
Width of steel track shoe |
200mm |
|
PERFORMANCE PARAMETER |
|
|
Standard Bucket capacity |
0.025m³ |
|
Swing speed |
12~13rpm |
|
Maximum Grade ability |
58%(30°) |
|
Maximum Bucket digging force |
9KN |
|
Maximum Arm digging force |
5.5KN |
|
Hydraulic system pressure |
20Mpa |
|
Machine weight(with canopy) |
1350kg |
|
Machine weight(with closed cabin) |
1480kg |
|
Boom length |
1700mm |
|
Arm length |
800mm |
|
Fuel tank capacity |
14.5L |
|
Hydraulic oil tank capacity |
14.5L |
|
MACHINE SIZE |
|
|
Overall dimension (L*W*H) |
3329mm*990/1300mm*2267mm |
|
Axle base(Track length on ground) |
1190mm |
|
Length of rubber track |
1600mm |
|
Track gauge |
790/1100mm |
|
Minimum Ground clearance |
153mm |
|
Swing radius at tail |
655mm |
|
Swing radius at front |
1812mm |
|
WORKING RANGE |
|
|
Maximum Digging height |
2955mm |
|
Maximum Dumping height |
2077mm |
|
Maximum Digging depth |
2017mm |
|
Maximum Vertical digging depth |
1610mm |
|
Maximum Digging distance |
3529mm |
|
Maximum Lifting height of blade |
236mm |
|
Maximum Cutting depth of blade |
229mm |
|
Boom swing angle(Left/Right) |
50°/52° |
