Power |
162KW/2000RPM |
|
Rated loading capacity |
5T |
|
Bucket capacity |
3m³ |
|
Maximum dumping height (blade plate) |
3100mm |
|
Operating weight |
16800kg |
|
Corresponding dumping distance(blade plate) |
1316mm |
|
Maximum breakout force |
140KN |
|
Minimum turning radius |
6710mm |
|
Pilot valve |
Single handle |
|
Maximum torque |
950Nm/1300~1600rpm |
|
Wheel tread |
2150mm |
|
Wheel base |
3200mm |
|
Minimum ground clearance |
440mm |
|
Tyre size |
23.5-25-16pr |
|
Bucket ascending time |
6s |
|
Bucket dumping time |
1.5s |
|
Bucket ascending time |
4s |
|
Gears |
Front 2 rear 1 |
|
Service brake |
Air-push oil caliper disc brake |
|
Parking brake |
Air break braking |
|
Forward speed |
36.5km/h |
|
Astern speed |
16.5km/h |
|
Bucket recovery angle |
48 |
|
Steering angle |
40 |
|
Dumping angle |
45 |
|
Gradeability |
30 |
